Specifications
Function / Model
FR207C
FR207D
Accuracy
AC Current (A)
60 / 600 / 1000A
60 / 600 / 1000A
±(2%+5)
INRUSH Current (A)
60 / 600 / 1000A
60 / 600 / 1000A
±(2%+5)
DC Current (A)
60 / 600 / 1000A
60 / 600 / 1000A
±(2%+5)
DC High Voltage (V)
1000V
1700V
±(0.5%+5)
AC High Voltage (V)
1000V
1000V
±(0.5%+5)
LowZ AC / DC Voltage (V)
100 ~ 1000V
100 ~ 1000V
±(1.5%+5)
ACV / Bandwidth (Hz)
1kHz
1kHz
–
ACA / Bandwidth (Hz)
60HZ
60HZ
–
Frequency (Hz)
10MHZ
20MHZ
±(0.5%+5)
Resistance (Ω)
600Ω / 6kΩ / 60kΩ / 600kΩ
600Ω / 6kΩ / 60kΩ / 600kΩ
±(1%+5)
6MΩ / 60MΩ
6MΩ / 60MΩ
±(2%+5)
Capacitance (F)
60nF ~ 600nF ~ 600uF
60nF ~ 600nF ~ 600uF
±(4%+5)
6000uF / 60000uF
6000uF / 60000uF
±(8%+5)
Temperature (℃)
–
1000°C
±(1.5%+4)
Temperature (℉)
–
1832°F
±(2%+5)
FEATURES
Display Counts
6000
Auto Range
●
True RMS
●
ACA PEAK
●
ACV VFD
●
Continuity / Diode
●
NCV (Red LED Flashing)
●
AC Live
●
Max / Min
●
Zero / Rel
●
