Specifications
SPECIFICATIONS
Function / Model
FR201E
FR202E
Accuracy
AC Current (A)
2.000A 20A / 200A / 500A
4.000A 40A / 400A / 600A
±(3.5%+30) ±(2%+5)
DC Voltage (V)
200mV / 2V / 20V / 600V
400mV / 4V / 40V / 600V
±(0.5%+3)
AC Voltage (V)
2V / 20V / 600V
4V / 40V / 600V
±(0.8%+3)
ACV / Bandwidth (Hz)
400Hz
400Hz
–
Frequency (ACV Hz)
–
10Hz ~ 40kHz
±(0.5%+5)
Resistance (Ω)
200Ω / 2kΩ / 20kΩ / 200kΩ 2MΩ / 20MΩ
400Ω / 4kΩ / 40kΩ / 400kΩ 4MΩ / 40MΩ
±(1%+5) ±(2%+5)
Capacitance (F)
–
40nF ~ 400nF ~ 400uF 4000uF
±(4%+5) ±(8%+5)
Temperature (℃)
–
(-20℃ ~ 1000℃)
±(1.5%+4℃)
Temperature (℉)
–
(-4℉ ~ 1832℉)
±(2%+5℉)
FEATURES
Display Counts
2000
4000
Jaw Opening
Φ30mm
Auto Range
●
●
True RMS
●
●
Continuity / Diode
●
●
NCV (Red LED Flashing)
●
●
AC Live
●
●
Auto power off
●
●
Max / Min
●
●
Zero / Rel
●
●
Backlight / Torch
●
●
Battery
AAA 1.5V×2
Category Ratings
CAT III 300V CAT II 600V
