Specifications
Model
FR205B
FR205D
Maximum count
4000 Count
6000 Count
Range switching
Auto
DC voltage
0.1mV~400.0V ±(0.8%+5)
0.1mV~600.0V ±(0.8%+5)
AC voltage
0.000V~400.0V ±(0.8%+5)
0.000V~600.0V ±(0.8%+5)
DC Current
–
0.00A~600.0A ±(2.0%+5)
AC Current
0.00A~400.0A ±(2.0%+5)
0.00A~600.0A ±(2.0%+5)
Capacitance
0.000nF~40.00mF ±(3.0%+5)
0.000nF~100.0mF ±(3.0%+5)
Resistance
0.0Ω~40.00MΩ ±(1.0%+3)
0.0Ω~60.00MΩ ±(1.0%+3)
Frequency
1.00Hz~10.00MHz ±(1.0%+3)
Duty cycle
0.1%~99.9% ±(1.0%+3)
Temperature
-20~1000°C; -4~1832°F; ±1.0% reading or ±3°C
AC Voltage/Current Frequency Response
40Hz ~ 500Hz
Jaw size
28mm × 42mm
True RMS
Have
Max/Min
Have
Data retention
Have
Diode
Have
On-off test
Have
Zero/Fire-line judgment
Have
1 Meter Drop Test
Have
Backlight
Have
LCD Size
38.8mm × 30mm
Electric Supply
Two 1.5V batteries (2×AAA)
Safety Grade
CAT III 600V / CAT IV 600V
Product Weight
Approx. 332g (without battery)
Meter Size
218mm × 76mm × 38mm
IP
IP45
