Specifications
Direct Use on Lives
Apply to and Removal from Hazardous
Live Uninsulated Conductors Permitted
Fast Audible Continuity
Quick Open-short Tests on
Switches, Fuses, and Wires
Clamp-on Hz
Measures Non-Invasive Current Frequency
Via Clamp Jaws; 20Hz to 400Hz
DCA, ACA, DC+ACA
Each 2 Ranges: 200.0A and 2000A
DCV, DC+ACV
Each 4 Ranges: DCV 6.000V to
1500V; DC+ACV 6.000V to 1000V
UL Listed CAT IV 1kV
Utility Applications for CAT IV Areas
Dual UL Listed CAT III 1500Vdc
For Photovoltaics, Battery Banks, Metros,
and Other DC Systems Applications
AC-Coupled ACV
4 Ranges: 6.000V to 1000V
AC Line-Level Hz
Measures Noisy High Voltage Frequency
via Test leads; 10Hz to 1999Hz
VFD-ACV + VFD-Hz
VFD-ACV 4 Ranges: 6.000V to
1000V; VFD-Hz 10 to 400Hz
PC-Comm Interface Capability
Optional Purchase USB
Cable & PC Software Set
VFD
(Low Pass Filter)Measures Fundamental V and Hz
of Most Variable-Frequency-Drives
EMC EN61326-1 Compliance
Superior Immunity to Interferences with
Reliable Operations and Readings
Fast Auto-Ranging
Shortens the Time to Measure
and Increases the Ease of Use
Back-Lighted LCD
Easy Display Viewing in the Dark
Manual-ranging Override
Auto-ranging with User Selectable
Manual-ranging Override
Rugged & Durable
High-impact Fire-retarded Housing
with Battery Access Door
Large 55mm DC/AC Jaws
Measure both DC and AC Non-invasive
Currents up to 2000A
Wide-Range Resistance
6 Full Ranges 600.0Ω To 40.00MΩ
Relative Zero Mode
Convenient Readings
Comparison & Offset
AC, AC+DC True RMS
Ideal for Non-sinusoidal & Complex
Waveforms of Voltages and Currents
Diode Test
Quick Checks on Diodes and Rectifiers
Wide-Range Capacitance
6 Full Ranges 60.00nf to 2000µF;
Measures Start & Run Motor Capacitors
Data HOLD
Freezes the Displaying
Reading for Later View
Type-K Temperature
Selectable °C or °F Readings;
Comes with a Bkp60 Bead Probe
5ms Crest-MAX
Fast Capture of In-Rush Current
or Voltage Spikes; Automatic
APO Disable Feature
Ergonomic & Streamlined Body
Fits Nicely with Single-Handed
Rotary Switch Operation
Auto Power Off
Intelligently Turns Off Automatically
to Extend Battery Life
Convenient Dual Display
ACA+Hz or ACV+Hz Readings;
6000 Counts + 2000 Counts
Transient Protection
12kV 1.2/50µS Lightning or Switching
Surge Protection for Serious Users
EF-Detection
Both Non-Contact (NCV) & Single-Probe
Voltage Detection for Identifying Live Lines
1500Vdc Input Protection
Superb Protection for Misinput
on All Functions and Ranges
