Specifications
Models
TC03A/9Hz
TC03A/25Hz
TC03A PRO/50Hz
IR Resolution
384 x 288
SuperResolution
Yes, up to 768 x 576
Pixel size
12 μm
Temperature range
-20 ℃ to 150 ℃, 100 ℃ to 550 ℃
Temperature accuracy
± 2% of rdg. or ± 2 °C, whichever is greater
(@ 23 °C ± 5 °C ambient temperature)
Frame rate
9 Hz
25 Hz
50 Hz
Focal length
10.5 mm
Focusing mode
Manual
Nonuniformity Correction (NUC)
Manual / Auto
Thermal sensitivity (NETD)
50 mK
45 mK
Spectral range
8 to 14 μm
Field of View (FOV)
25° x 19°
Spatial Resolution (IFOV)
1.14 mrad
USB Interface
Type C
Operating system supported
Android and HarmonyOS
Operating temperature
0℃ to 40 ℃
Storage temperature
-30 ℃ to 60 ℃
Operating humidity
10% to 90% RH (non-condensing）
Power consumption
700 mW (Typical)
Ingress protection
IEC 60529: IP54 (with the protective cover for Type-C)
Operating altitude
2000 m
Storage altitude
12000 m
Dimensions (L x W x H)
60 mm x 36 mm x 28 mm
Weight
55 g
Warranty
2 years
