Specifications
Function
Varistor (MOV) initial voltage leakage current test, discharge tube (GDT) discharge voltage test, insulation resistance test
Base condition
23℃±5℃, below 75%rh
Measuring voltage (V)
0.0V~3000.0V
Resolution: 0.1V
Accuracy: ±2%rdg±30dgt
Measuring leakage current (uA)
0.1uA~199.9uA
Resolution: 0.1uA
Accuracy: ±2%rdg±10dgt
Insulation resistance
10~1000MΩ
Discharge rate of discharge tube
(100±8) V/s
Power
11.1V Large capacity rechargeable battery
Backlight
Yes, suitable for use in dim places
USB data transmission
Have
Display mode
5-inch color TFT LCD
LCD display size
108mm × 65mm
Instrument size
240mm (L) × 188mm (W) × 85mm (H)
Test line
Test line red 1m, black 1m
Data storage
500 groups
Data review
Data review function: “MR” symbol display
Overflow display
Over-range overflow function: “OL” symbol display
Judging function
Measurement exceeds the setting range
Power consumption
Standby: 300mA Max, measure: 900mA Max
Weight
1230g (including battery)
Automatic shut-down
Instrument will automatic shut-down after 15 minutes no operation
Insulation resistance
≥50MΩ (1000V)
Pressure resistance
AC3kV/50Hz 1min
Working temperature and humidity
-10°C ~ +50°C < 85%RH
Production Compliance
IEC61010-1, IEC1010-2-31, IEC61557-1.5, IEC60529(IP54), Pollution Grade 2, CAT III 300V
IP
IP54
